Macrotrachela nana Bryce 1912
Macrotrachela nana, whirling, dorsal view, focal plane on the undivided upper lip (1). The rostrum is oval and is wider than the head.
Macrotrachela nana, same specimen as above, whirling, dorsalventral view, focal plane on the vitellarium with 4 nuclei. The diet of this specimen seems to be partly fungus spores. (1)
Macrotrachela nana, whirling, dorsal view, focal plane on the undivided upper lip. (2)
Macrotrachela nana, dorsoventral view, optical cross-section, focal plane on the trochal columns. The corona is smaller than the head. (2)
Macrotrachela nana, dorsoventral view, optical cross-section, creeping (2)
Macrotrachela nana, two aspects of the head dorsoventral view. Left image: focal plane on the upper lip. right image: focal plane on the trochal columns. The corona is smaller than the head. (2)
Macrotrachela nana, two aspects of the foot with spurs and three toes. (2)
Macrotrachela nana, compressed specimen showing the vitellaria with 4 nuclei each. (2). See also Macrotrachela nana var. ligulata.
Macrotrachela nana, creeping specimen from (3). The arrow points to the short dorsal antenna.
Macrotrachela nana, same specimen from (3). The arrows point to the 4 nuclei of the vitellarium.
Macrotrachela nana, whirling (3).
Location: Hattingen Oberstueter (1);Aneboda, Sweden (2); Ossian Sarsfjellet, James I Land, Svalbard (3)
Habitat: Tree moss (1);Spagnum moss (2); moss (3)
Date: 05.02. 2013 (1); 16.02.2014 (2); 16.10.2015 (3)
