| Philodinavus paradoxus: lateral view, whirling. The corona is very small compared to bdelloid rotifers of the Philodinidae. (1) |
| |
 |
| Philodinavus paradoxus: crop of the above image. The gastric glands are red. (1) |
| |
 |
| Philodinavus paradoxus: lateral view; focal plane on the foot with 4 toes (arrowheads) and the spurs. (1) |
| |
 |
| Philodinavus paradoxus: creeping specimen, dorsoventral view; peg-like spurs with interspace. (3) |
| |
| |
 |
| Philodinavus paradoxus: dorsal view, focal plane on the trophi. (1) |
| |
 |
| Philodinavus paradoxus: ventral view (1) |
| |
 |
| Philodinavus paradoxus: foot with 4 toes and spurs. (1) |
| |
 |
| Philodinavus paradoxus: focal plane on the foot with 4 toes (arrowheads) and the spurs (Sp). (1) |
| |
| |
| Philodinavus paradoxus: trophi (1) |
| |
 |
| Philodinavus paradoxus: specimen from (2), whirling |
| |
| |
|
| Philodinavus paradoxus: 4 images of the ramate trophi; upper images: cephalic view, different focal planes on the macerated trophi with dental formula (DF) 3/3; rami length (RaL): 15µm. Lower images: during the maceration process some epipharyngeal structures (arrowheads) detached from the trophi. right image: dorsoventral view. (3) |
| |
| |
| |
|
|
| |
| |
|
|
| |
| |
| |
| Location (2): Kalkbach, St. Ulrich, Tirol, Austria |
| Habitat(2): between moss in lotic water (1); between cyanobacteria (2) |
| Date: 27.06.2014 (2); |
|
|
